Specification
| Model | HSR-2D102 |
HSR-2D202 |
HSR-2D302 |
HSR-2D402 |
HSR-2D502 |
HSR-2D702 |
|
| Load | Rated load voltage | 100 - 240 V AC | |||||
| Power supply voltage | 90 - 264 V AC | ||||||
| Peak voltage (no repetition) |
600 V | 800 V | |||||
| Rated load current | 10 A | 20 A | 30 A | 40 A | 50 A | 70 A | |
| Frequency | 25 - 65 ㎐ | ||||||
| Input current | 170 A | 250 A | 315 A | 580 A | |||
| Leakage current | 10 ㎃ | 15 ㎃ | |||||
| Output ON voltage dropping | 1.3 V | 1.6 V | 1.8 V | ||||
| Min operation current | 1 A | 0.5 A | |||||
| Response speed | 1/2 cycle + 1 ㎳ max. | ||||||
| Max 1 ㎳ | |||||||
| Input | Rated voltage | 5 - 24 V DC | |||||
| Usable voltage range | 4 - 32 V DC | ||||||
| Impedance | Max 4 ㏀ | ||||||
| Operation voltage | Min 3 V DC | ||||||
| Return voltage | Max 1.5 V DC | ||||||
| Input current | Constant current method : 10 ㎃ (±3) | ||||||
| Insulation resistance | 500 V DC, 100 ㏁ (Between the input / output and case) | ||||||
| Dielectric strength | 2,500 V AC (for 1 min at 60㎐) | ||||||
| Vibration resistance | 10 - 55 ㎐ Double amplitude : 1.5 ㎜, each X, Y and Z direction for 2 hour | ||||||
| Shock resistance | 1,000 ㎨, X,Y,Z each X, Y and Z direction for 3 times | ||||||
| Storage temperature | -30 ℃ ~ 90 ℃ | ||||||
| Ambient temperature | -20 ℃ ~ 80 ℃ | ||||||
| Ambient humidity | 45 ~ 85 % RH | ||||||
| weight | Approx 150 g (included the weight of box) | ||||||
