Sensing type
Diffuse reflective
Sensing distance
700mm
Sensing target
Opaque, Translucent material
Light source
Infrared LED (940nm)
Response time
<20ms
Power supply
24-240VAC~ ±10% 50/60Hz, 24-240VDC ±10%(ripple P-P: max. 10%)
Current consumption
<3VA
Sensitivity
Adjustable
Operation mode
Light On / Dark On selectable
Control output
Relay
Timer function
Yes
Connection type
Terminal block
Environment illumination
Sunlight: <11000lx, Incandenscent lamp: <3000lx
Operating temperature
-20 to 55C
Operating humidity
35 to 85% RH
Liquid / dust protection
IP66
Approval
CE
Mass
116g
