Ez~Air Toyo fans have been used in the electrical and automation industries for decades, providing quiet and efficient cooling to panels, electricals and electronics assembly.
These compact axial fans are suitable for high air flow with moderate pressure build-up. The air flow is parallel to the axis of rotation.
Design Feature
a. Ball bearing system allows for operation in any position
b. Impeller &Housing: Plastic with fiber glass filled UL 94V-0
c. Die cast aluminum painted black frame
d. Thermal protection
e. 1.2m wire leads
Specifications
Model Voltage Flow Rate Current Power Speed Static Press Noise
50/60Hz (CFM) A W RPM (Inch H2O) (dBA)
FP108HH 110/120 460/550 0.32/0.30 35/30 1500/1650 0.35/0.45 48
220/240 460/550 0.15/0.14 33/31 1500/1650 0.35/0.45 48
Dimensions
